Untitled document TS-Series Thermal imaging cameras for wildlife observations The FLIR Scout TS-Series are rugged handheld thermal imaging cameras that have been especially developed for wildlife observations and hunters. Thermal imaging cameras need no light whatsoever to produce an image. They help you to see clearly at night, in practically all weather circumstances. Scout, powered by the same advanced technology used by military and law enforcement, is the first personal thermal imaging camera affordable enough to give every outdoorsman the unsurpassed practical advantages of full-resolution thermal imaging night vision. Scout makes images from heat, not light, a feat impossible for the naked eye or even image intensified (I2) night vision devices, which means you can see clearly even without any visible light at all. People, animals, and objects all make their own heat and their own contrast, and are clearly seen by the Scout in even the most adverse conditions. After sunset, a lot of animals are active. With the help of a thermal imaging camera like the TS-Series you will be able to monitor their activities. The TS-Series will not only help you to find animals in total darkness but during daylight as well. Thermal imaging cameras make extremely small temperature differences visible. Based on these temperature differences they create a clear image. Furthermore, thermal contrast is extremely difficult to mask. This means that during daylight you will clearly see animals that are hidden in trees or bushes. Their natural camouflage will not help them to hide anymore. Thermal imaging cameras are widely used by professional documentary makers and hunters worldwide. Until now they have been extremely expensive. The TS-Series are now bringing thermal imaging cameras within reach of nature and wildlife enthusiasts and for hunters.
InstAlertTM The unique InstAlert feature colors the hottest parts in the thermal image red. This makes it extremely easy to spot animals in the thermal image.
Crisp thermal images, choice of image quality The TS-Series produces thermal images of 240 x 180 or 320 x 240 pixels on which the smallest of details can be seen. Advanced internal camera software delivers a crisp image without the need for user adjustments. Different versions available The TS Series is available in a Basic and a Pro version. The Pro versions contain useful features such as still image and video storage. The images and video can be used to insert in your own video or photo collection. Wide angle lens The TS-Series are providing a 24° field of view. It offers an excellent combination of range performance and situational awareness. A deer for example can be spotted at about 450 meters away, in total darkness. For situations where longer range performance is needed a 2X extender is available. It spots a deer at approximately 790 meters.
For even longer range performance, the TS32r is available. It is equipped with a 7° lens. Due to the narrow field of view it can be used to spot a deer at about 1,450 meters away. Hot Shoe & Shutterd Eyepiece The TS-Series come standard with a “Hot Shoe”. Not only does it allow for tripod mounting of the TS-Series it also has a power in and video out jack. This means that you can put the TS-Series in a certain position and follow what is happening from a hidden location, on a large monitor. The shuttered eyepiece keeps light from coming out of the viewfinder and avoids alarming animals or other target subjects. Technical Specifications: The FLIR Scout TS-Series are rugged handheld thermal imaging cameras that have been especially developed for wildlife observations and hunters. Thermal imaging cameras need no light whatsoever to produce an image. They help you to see clearly at night, in practically all weather circumstances. General specifications: IMAGING PERFORMANCE Detector type Uncooled Focal plane array Vanadium Oxide (VOx) microbolometer Spectral range 7.5 to 13.5 µm Thermal sensitivity <50 mK at f/1.0 at +25°C Image frequency 8.3 Hz Pal Image processing Digital Detail Enhancement (DDE) IMAGE PRESENTATION Viewfinder LCD screen Video output PAL composite video; RCA jack Image polarity White hot / black hot; selectable InstAlert On-screen symbology Standard POWER Requirements 4 AA Batteries; rechargeable NiMH (included), non-rechargeable Li-Ion or Alkaline Battery life > 5 hours on NiMH batteries - 120 hours in stand-by with NiMH batteries ENVIRONMENTAL SPECIFICATIONS Humidity non condensing 5% to 95% Encapsulation IP67 Drop Operational after 1 m drop onto concrete STANDARD PACKAGE Camera, Hot Shoe, 4 Rechargeable AA Batteries, AC Power Adapter/Charger, Car Adapter/Charger, Neck Lanyard, Operator's Manual, USB Cable, Video Output Cable, SD Card. Specification: Image Resolution 320 x 240 Field of View - H x V 24° x 18° Field of View w/Optional 2X Extender – H x V 12° x 9° Freeze Image on LCD display No SD /SD HC Card enabled (up to 16Gb) Yes Still Image Storage on SD /SD HC Card Yes Video Storage (MPEG -4) on SD /SD HC Card Yes 2x Digital E-Zoom Yes Diopter Adjustment + 2 Yes US B2 Port (for SW updates/upgrades) Yes Weight incl. batteries (w/o 2X Extender) 1.59 lb (721 g) Size - L . W . H (w/o 2X Extender) 9.36” x 3.33” x 2.62” (256 x 84.5 x 66.5 mm) Operating Temp. 32°F to +122°F (0°C to +50°C) Storage Temp. -4°F to +158°F (-20°C to +70°C) Common Features Detector Type Longwave Uncooled VOx Microbolometer Video Output (9 Hz refresh rate) NTSC or PAL composite video; Aux Video Outout available via RCA jack on detachable Hot Shoe Built-In Viewfinder Display Color VGA LCD with brightness control and on-screen symbology Power Button On / Off / Standby Start up from stand-by <1.5 seconds Battery Type 4 AA NiMH Batteries (included); Li-Ion or Alkaline optional (not included) Battery Life (Operating / Stand-By) >5 Hours / ~120 Hours (on included NiMH batteries) Battery Recharging Detachable Hot Shoe Charging Port for AC Power Adapter/Charger -or- Car adapter/Charger (both chargers and Hot Shoe included) Polarity / Detection Palettes Selectable Black Hot, White Hot or FLIR “Instalert”; FLIR Proprietary Digital Detail Enhancement Fixed Use Standard tripod mount Rating / Environmental IP-67, Submersible, 1 m drop Performance Range Performance* with std 24° Lens / with 2. Extender ~500 yds (~460 m)/ ~900 yds (~825 m) Detect Man sized target (~1.8 m . 0.5 m) |
