Untitled document - Photo engraved rangefinding reticle
- Full multicoating and anti-reflection treatment eliminating glare and maximizing light transmission
- 6061-T6 alloy housing, "O" ring sealed and nitrogen filled
- Waterproof
- Fogproof
- Shockproof
- High resolution optic system
- Magnum lock support system on reticle
- Superior optical glass by Schott Glasswerk, Germany
Magnification: | 2,5 - 10x | Objective-Lens Diameter: | 42 mm | Lighttransmission | min. 90% | Tube diameter: | 30 mm | Diopter adjustment: | -4 až +4 dpt | Click adjustment: | 1/2 MOA (MP-8, MIL-DOT, Dragunov)1/2 inch (7A, 4A, 1A, 6DOT) | Reticle adjustment range: | 88 MOA | Reticle Type: | MP-8 | Illuminated reticle: | MP-8 | The batterie type: | Lithium 3V CR 2032 | Field of view (FOV): | 6,8 ° - 2 ° | FOV at 100m: | 11,9 – 3,5 m | Exit pupil diameter: | 11 – 4,2 mm | Exit pupil distance: | 75 mm | Lenght: | 360 mm | Weight: | 520 g | Optical components (glass): | Superior optical glass by SCHOTT (Germany) | Antireflex treatment: | T3 multilayer coating (Carl Zeiss) | Working temperature: | -30 to +50 | Scope body material: | 6061-T6 alloy housing | Surface coating: | 2 - layers matt black | |
