Untitled document - Etched or photo engraved glass reticle
- Full multicoating and anti-reflection treatment eliminating glare and maximizing light transmission
- 6061-T6 alloy housing, "O" ring sealed and nitrogen filled
- Waterproof
- Fogproof
- Shockproof
- High resolution optic system
- Magnum lock support system on reticle
- Superior optical glass by Schott Glasswerk, Germany
Magnification: | 2,5 - 10x | | Objective-Lens Diameter: | 42 mm | | Tube diameter: | 30 mm | | Diopter adjustment: | +/-4 dpt | | Click adjustment: | 1/2 MOA | | Reticle adjustment range: | 88 MOA | | Reticle Type: | 8H | | Illuminated reticle: | 8H | | The batterie type: | Lithium 3V CR 2032 | | Field of view (FOV): | 6,8 ° - 2 ° | | FOV at 100m: | 11,9 – 3,5 m | | Exit pupil diameter: | 11 – 4,2 mm | | Exit pupil distance: | 75 mm | | Lenght: | 360 mm | | Weight: | 550 g | | Optical components (glass): | Superior optical glass by SCHOTT (Germany) | | Antireflex treatment: | T3 multilayer coating (Carl Zeiss) | | Working temperature: | -30 to +50 | | Scope body material: | 6061-T6 alloy housing |
|
