Company Dedal-NV was created in 1991 (in the period of strong competition among 50 Russian enterprises that worked in night vision systems production) on the base of Russian state defense industry enterprise in the course of defense industry conversion.
Application • Police / Law enforcement
• Night surveilance / Hunting
• Patrol / Rescue / Search Features • 4x magnification
• Gen II+
• Shockproof even with heavy recoil (incl. .375H&H cal.)
• Special high light transmission optics
• Long eye relief
• Centered MIL-DOT reticle with adjustable brightness at the centre
• Precision tactical windage/elevation adjustment (1/2 MOA)
• Powerful hazard-free IR illuminator (75 mW)
• Wide range of mounts
• Water resistance
• Extremely light weight Technical characteristics: General: | | Dedal-450 | | Magnification, x | 3.7 | | Field of view, deg | 8.6 | | Objective | 100 mmF/1.5 | | Eye relief distance, mm | 55 | | Diopter setting, D | +3, −4 | | Dimensions, mm | 310×85×75 | | Weight, kg | 0.93 | | The power supply — battery of a type AA | 2 pc | | Feed voltage, V | 3 | | Battery life, h | min. 60 |
Image intensifier tube: | Type tube | Gen. II+ | | Photocathode sensitivity, µA/lm | 340 - 600 | | Gain | 25 000 – 45 000 | | Resolution, lp/mm | 36 - 50 |
Conditions of the work: | Operating temperature | −40 °C to +50 °C | | Relative humidity, % | up to 98 |
|
